Pre-torq Chuck Rubbers To Fit Kalish®



Rubber Parts To Fit Kalish® Monoblock Cappers And Pretorquers

Stiles has accumulated tooling to produce an assortment of chuck insert sizes to fit Kalish® pretorquers.

Click the Overhead Chuck Inserts Link for station 2 cap tightening rubbers.

If you are using these parts, contact us.


Capper Change Parts To Fit:

  • Resina® Cappers
  • Kaps-All® Cappers
  • White Cap® Cappers
  • Pack West® Cappers
  • IMA® Cappers, MAR® Cappers
  • Sure Cap® Cappers
  • National Instrument® Cappers
  • Filamatic® Cappers
  • N.E.M® Cappers
  • Pneumatic Scale® Cappers
  • ELF® Cappers
  • Inline® Cappers
  • Newman® Cappers
  • Kinsley® Cappers
  • Kalish® Cappers
  • CAPEM® Cappers
  • Other Cappers

Capper Links

After The Part Number Add The Suffix Which Specifies The Desired Material And Hardness
Example: AB-02393-AGD

Material Suffix

Shore A Durometer

Color

Compound Number

AGD
(Standard Hardness)

40

Clear

1540

AGE

50

Clear

1550

AGG

60

Clear

1560
Pretorque Rubber Drawing


 We Stock More Capper Chuck Inserts And Torque Wheels Than Anyone

Torque Wheels • Chuck Inserts • Capper Belts • Bottle Gripper Rubbers • Table Top Chain • Rubbers To Fit Resina® Side Chain



AB-02767

  • A_ 0.72
  • A2_0.62
  • B_ 0.455
  • B1_0.125
  • B2_0.33
  • C_ 0.187
 AB-02767-AGG Capper Pre-torquer Chuck Insert For Kalish®



AB-02390

  • A_ 0.85
  • A2_0.74
  • B_ 0.50
  • B1_0.125
  • B2_0.375
  • C_ 0.187
 CB-02419-AIN Capper Pre-torquer Chuck Insert For Kalish®



AB-02391

  • A_ 1.0
  • A2_0.89
  • B_ 0.687
  • B1_0.125
  • B2_0.562
  • C_ 0.187
 AB-02391-AGG Capper Pre-torquer Chuck Insert For Kalish®



AB-02392

  • A_ 1.125
  • A2_0.945
  • B_ 0.937
  • B1_.187
  • B2_0.75
  • C_0.25
 AB-02392-AGE Capper Pre-torquer Chuck Insert For Kalish®



AB-14445

  • A_ 1.310
  • A2_1.14
  • B_ 0.938
  • B1_0.188
  • B2_0.75
  • C_ 0.375
 AB-14445-AGE Capper Pre-torquer Chuck Insert For Kalish®



AB-02393

  • A_ 1.437
  • A2_1.280
  • B_ 0.937
  • B1_0.187
  • B2_0.75
  • C_0.50
 AB-02393-AGE Capper Pre-torquer Chuck Insert For Kalish®



AB-02394

  • A_ 1.625
  • A2_1.485
  • B_ 0.937
  • B1_0.187
  • B2_0.75
  • C_0.50
 AB-02394-AGE Capper Pre-torquer Chuck Insert For Kalish®



AB-02395

  • A_ 1.812
  • A2_1.670
  • B_ 0.9375
  • B1_0.1875
  • B2_0.75
  • C_ 0.50
  • Interchangeable with AB-02615
 AB-02395-AGE Capper Pre-torquer Chuck Insert For Kalish®



AB-02615

  • A_ 1.812
  • A2_1.670
  • B_ 0.9375
  • B1_0.1875
  • B2_0.75
  • C_ 0.625
 AB-02615-AGE Capper Pre-torquer Chuck Insert For Kalish®



AB-02614

  • A_ 2.125
  • A2_2.00
  • B_ 0.937
  • B1_0.187
  • B2_0.75
  • C_ 0.75
 AB-02614-AGE Capper Pre-torquer Chuck Insert For Kalish®



AB-10317

  • A_4.25
  • A2_3.0
  • B_1.187
  • B1_0.25
  • B2_.937
  • C_1.50
 AB-10317-AGE Capper Pre-torquer Chuck Insert For Kalish®



AB-10083

  • A_ 3.25
  • A2_3.062
  • B_ 1.125
  • B1_.1875
  • B2_.9375
  • C_ 1.50
 AB-10083-AGE Capper Pre-torquer Chuck Insert For Kalish®



AB-10318

  • A_ 4.00
  • A2_3.812
  • B_ 1.125
  • B1_0.1875
  • B2_0.9375
  • C_ 1.50
 AB-10318-AGE Capper Pre-torquer Chuck Insert For Kalish®s







Click Picture For Kalish® Station 2 Overhead Chuck Insert Rubbers
Overhead Rubber Chuck Inserts For Station 2
