We Work With The Best Manufactures To Give You The Best Solutions

Habasit's polyamide folder-gluer belts fulfill all the requirements of common box folding processes. The rubber covers provide high durability, good positive grip, and the ability to cope with rough conditions.

These belts are also suitable for tube winders.

Main Features:

  • Good dimensional stability and precise folding
  • Proven NBR rubber covers with good abrasion resistance
  • No marking, and gentle treatment of goods


  • Polyamide folder-gluer belts are available in two different constructions:

  • The "traditional" version with a traction layer consisting of PA foil and PA fabrics. These types are joined by gluing (using the Thermofix joining system). The belts are suitable for machine speeds of up to 600 m/Minute.
  • The more sophisticated types feature a thermoplastic foil traction layer combined with polyamide fabrics allowing adhesive-free joining (using the Flexproof method). These belts are suitable for machine speeds of up to 300 m/Minute.


  • Warranties Folder Gluer Belts: Polyamide
    Folder Gluer Belts Application PDFFlexfold ® CT Series PDFs
      Thickness Pulley Dia. (Minimum) Tensile force for 1% elongation (k1% after running in)

    Conveying Side

    (1)

    Traction layer

    (2)

    Running Side/Pulley Side

    (3)

    Product code Click Pic For Detail  mm  mm N/mm Material Property Color Material Material Property Color
    XVT-2213 XVT-2213 4   7 Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Light green Polyamide (PA) fabric Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Yellow
    XVT-2226 XVT-2226 5   7 Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Light green Polyamide (PA) fabric Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Yellow
    XVT-2236 XVT-2236 6   7.5 Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Light green Polyamide (PA) Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Yellow
    XVT-2237 XVT-2237 3   5 Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Light green Polyamide (PA) Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Yellow
    XVT-2238 XVT-2238 4   5 Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Light green Polyamide (PA) Acrylonitrile-Butadiene-Rubber (NBR) Adhesive Yellow

    For Additional Information And Delivery Information Call Our Office


    .
