We Work With The Best Manufactures To Give You The Best Solutions

UHMW-PE Tape Series is natural (opaque) in color and is produced from an ultra-high molecular weight polyethylene.

These tapes are manufactured by applying a rubber adhesive* to a UHMW-PE film and are excellent for applications involving surface wear. Additionally, their excellent anti-stick, reduced friction and noise-reduction properties make them ideal for mechanical applications such as chute linings, conveyor systems and guide rail applications.

These tapes have received USDA approval for food processing and handling, and are FDA compliant (21 CFR177.1550). Tapes with silicone adhesive operate over a wide temperature range, -100°F to 500°F (-73°C to 260°C), while tapes with acrylic adhesive operate over a narrower range of temperatures, -40°F to 350°F (-40°C to 177°C).

* Acrylic adhesive is available upon special request

Food and Beverage:

  • Anti-stick surface for dough making applications
  • Chutes, pans for cereal manufacturing
  • Tabletop surface liners
  • Hopper liners
  • Bottling line dump table liners
  • Release surface for sticky foods, candies
  • Skid surface for milk cartons
  • Can and bottle filling line surface protection
  • Belt protector
  • Materials Handling:

  • Conveyor side liners
  • Sheet bearings
  • Chute liners
  • Chain guides
  • Conveyor belt anti-friction surface
  • Wear plates and wear strips

    Environmental:

  • Wear strip for sludge collection    equipment
  • Wear plates and surfaces
  • Scraper blades
  • Other:

  • Sliding surfaces
  • Anti-stick surface
  • Anti-icing surface
  • Covering of work surfaces
  • Low friction rub strips
  • Glide surfaces or pads
  • Agriculture:

  • Gravity box lining
  • Grain chute liners
  • Harvester chute liners
  • Non-stick surface in seed / fertilizer spreader

  • Warranties Tape: UHMW-PE
    Applicable Splicing And Lacing OptionsPTFE TapePTFE Smooth Belts • PTFE Mesh Belts
    Material       Nominal Thickness Nominal Thickness  Adhesion Tensile Strength Elongation Dielectric Maximum Operating Full Width Slit Roll
    Lengths
    Suffix Picture Color Adhesive  (Substrate) (Adhesive) (oz./in. of width) (lbs/sq in) (%) Strength (Volts) Temperature inch Yards
    CAU Natural Rubber 0.005" 0.005" 90 30 300 15,000 225°F (107°C) 25 18, 36
    CAV Natural Rubber 0.010" 0.005" 90 60 300 30,000 225°F (107°C) 25 18, 36
    CAW Natural Acrylic 0.005" 0.0018" 50 30 300 15,000 350°F (177°C) 25 18, 36
    CAX Natural Acrylic 0.010" 0.0018" 50 60 300 30,000 350°F (177°C)

    Disclaimer:

    The Manufacturer measures tensile strength according to ASTM D828 and adhesion according to D 3654/D 3654M. The figures above are averages and actual results will vary.

    For Additional Information And Delivery Information Call Our Office

    .
