We Work With The Best Manufactures To Give You The Best Solutions

Attributes Of Silicone:

  • High temperature resistance
  • Good release properties
  • High chemical resistance
  • Good UV resistance
  • Negatives:

  • Low tensile strength
  • Low abrasion resistance
  • Difficult to glue
  •

    Warranties Silicone Food Belting

    PTFE Glass BeltsPTFE Mesh BeltsSilicone Glass Belts

      Thickness Pulley Dia. (Minimum) Tensile force for 1% elongation (k1% after running in) Conveying Side Traction layer Product Characteristics
     Code Click Pic For Detail  mm  mm  N/mm Material Surface Property Color Qty of Fabrics Antistatic Nosebar suitable
    FAB-5ER 10 FAB-5ER-10 Silicone / Polyester Food Belting 1 15 5 Silicone (SI) Smooth Super-adhesive White 2 No Yes
    FNI-5ER 10 FNI-5ER-10 Silicone / Polyester Food Belting 0.9 15 5 Silicone (SI) Impregnated fabric Non-adhesive White 2 No Yes
    .
