Elastic Flat Belting:

Stretch / unsupported belts are used for conveying and drive applications. Elastic belts are available in urethane, and other elastomers not listed.

Also be sure to check our non reinforced round belting as an alternative option.

Many of the urethane belts can be spliced together with heat fusing equipment without using adhesives. Stretch elastic belts are often the solution for systems without tensioning devices.

Warranties Elastic And Semi Elastic Flat Belting
Also Consider stretch round belts and non reinforced urethane belting
  Thick Pulley Dia. (Minimum) Tensile force elongation per unit of width (See PDF Spec Sheet) Conveying Side Traction layer Running Side/Pulley Side
Code Click Pic For Detail  mm  mm N/mm Elongation Material Surface Property Color Material Material Surface Color
MAB-02 MAB-02 1.2 15 1.4 8% TPU Fine textile structure Medium-adhesive Green TPU PUR Fine textile structure Black
MAB-05 MAB-05 1.5 15 3.3 8% TPU Fine textile structure Medium-adhesive Green TPU PUR Fine textile structure Black
MAM-04H MAM-04H 1.45 15 2.6 8% NBR Fine  Adhesive Green Hamid NBR Rough Black
MAM-05HP MAM-05HP 1.6 15 3.2 8% NBR Fine  Adhesive Green Hamid NBR Rough Textile  Black
MAN-05H MAN-05H 1.9 20 5 8% PET fleece Non-woven (fleece) Adhesive Anthracite Hamid NBR Rough Textile  Black
MAT-02H MAT-02H 1.4 15 0.9 8% NBR Rough  Adhesive Green Hamid NBR Rough  Black
Call For Available Sizes And Delivery Orange Urethane Flat Belts


For Additional Information And Delivery Information Call Our Office


.
