We Work With The Best Manufactures To Give You The Best Solutions

Habasit HySan® Food Belts are superior to standard food PVC belts and competitors’ high-grade PVC belts (both similar constructions).

In a meat processing line, extraction of plasticizer in typical PVC-coated conveyor belts lead to severe cracking – a major hygiene risk.

HySan® Advantages:

Temperature resistance in oily conditions • Broad temperature tolerance (-10 °C/ +90 °C) for a wide range of applications • Full compliance with food regulations (FDA, USDA, EU) Improved service life • HySAN negotiates smaller pulley diameter at elevated temperatures • HySAN features higher abrasion resistance HySAN belts are available in various constructions, colors, and thicknesses

Warranties Habasit HySan® Food Belts Literature
Call Stiles For Replacement Conveyor Chain Gripper Rubbers
  Thick Pulley Dia. (Min) Tensile force for 1% elong. (k1% static) Conveying Side (1) Tract. Layer
Pulley Side
Code Click Pic For Detail  mm mm N/mm Material Property Color Number of Fabrics Color Surf Flame Retard Spec Metal Detect OK FDA Specs
FAB-10EVCW FAB-10EVCW Habasit HySan® Food Belt 3 60 10 PVC Matt Medium-Adhesive Blue 2 Blue No Yes Yes
FAB-12EOWV FAB-12EOWV Habasit HySan® Food Belt 2.8 60 12 PVC Matt Medium-Adhesive White 2 White Yes Yes Yes
FAB-8EOWV FAB-8EOWV Habasit HySan® Food Belt 2 25 10 PVC Matt Medium-Adhesive White 2 White Yes Yes Yes
FAW-8EOWV FAW-8EOWV Habasit HySan® Food Belt 2.1 25 10 PVC Waffle structure Medium-Adhesive White 2 White Yes Yes Yes
FNR-5RFWR FNR-5RFWR Habasit HySan® Food Belt 2.5 25 5 Polyester (PET)/Cotton (CO) fabric Fabric Non-Adhesive White 2 White No Yes Yes
FNT-8EEWE FNT-8EEWE Habasit HySan® Food Belt 1.6 20 10 Polyester (PET) Fabric Non-Adhesive White 2 White Yes Yes Yes

For Additional Information And Delivery Information Call Our Office
