We Work With The Best Manufactures To Give You The Best Solutions


HabaGuard® Anti Microbial Urethane Conveyor Belts were designed for the food industry.

These conveyor and processing belts contain an anti microbial additive that prevents the growth of spoilage micro-organisms on the belt surface.

Applications: Targeted Industries:
  • Discharging belt
  • Food processing/conveying belt
  • General conveying belt
  • Packaging belt
  • Transfer belt

  • Bakery (biscuit / cookie / bread)
  • Chocolate / confectionery
  • Dairy
  • Cheese
  • Fruit
  • Meat
  • Fish
  • Poultry
  • Vegetable


  • The anti microbial additive remains effective even in areas that are difficult to clean. It does not affect the taste of the foodstuff conveyed.
    Warranties HabaGuard Anti Microbial Conveyor Belting Literature
    Call Stiles For Replacement Conveyor Chain Gripper Rubbers
      Thick Pulley Dia. (Min) Tensile force for 1% elong. (k1% static) Conveying Side (1) Tract. Layer
    (2)
    Pulley Side
    (3)
    Properties
    Code Click Pic For Detail  mm mm N/mm Material Surface Property Color

    Number of Fabrics

    Color Anti Static Nose bar suitable
    FAB -2E +H15 FAB-2E+H15 HabaGuard® Anti Microbial Belt 0.7 15 3.6 Thermoplastic polyurethane (TPU) Smooth Adhesive White 1

    Light Blue

    Yes Yes
    FAB -5E +H15 FAB-5E+H15 HabaGuard® Anti Microbial Belt 1.3 15 6.5 Thermoplastic polyurethane (TPU) Smooth Adhesive White 2

    Light Blue

    Yes Yes
    FAB -8E +H15 FAB-8E+H15 HabaGuard® Anti Microbial Belt 1.6 20 8.5 Thermoplastic polyurethane (TPU) Smooth Adhesive White 2

    Light Blue

    Yes No
    FNB-12EVCQ +H15 FNB-12EVCQ+H15 HabaGuard® Anti Microbial Belt 1.9 20 10 Thermoplastic polyurethane (TPU) Smooth Non-adhesive Cobalt blue 2 Cobalt blue No No
    FNB -5E +H15 FNB-5E+H15 HabaGuard® Anti Microbial Belt 1.3 15 7 Thermoplastic polyurethane (TPU) Smooth Non-adhesive White 2

    Light Blue

    Yes Yes
    FNB -6EVWQ +H15 FNB-6EVWQ+H15 HabaGuard® Anti Microbial Belt 1.55 30 5.5 Thermoplastic polyurethane (TPU) Smooth Non-adhesive White 2 White Yes No
    FNB -8E +H15 FNB-8E+H15 HabaGuard® Anti Microbial Belt 1.6 20 8 Thermoplastic polyurethane (TPU) Smooth Non-adhesive White 2

    Light Blue

    Yes No


    For Additional Information And Delivery Information Call Our Office


    .
